GTI EL5 CLEANTECH
GTI EL5 CLEANTECH
The GTI EL5 CLEANTECH interlocking tile flooring by Gerflor is a high-performance solution engineered for environments requiring stringent electrostatic discharge (ESD) control, exceptional hygiene, and durability. This flooring system is ideal for sectors such as pharmaceuticals, biotechnology, electronics manufacturing, and healthcare facilities.
- Format: Heat-welded Tile
- Overall thickness: 0.24″ (6.0 mm)
- Evercare™ conductive surface treatment = no wax for life
- No ESD adhesive needed
- ISO 5 / GMP Class A
GTI EL5 CLEANTECH interlocking tile flooring provides a durable, sustainable, and efficient solution for critical environments where ESD control, hygiene, and quick installation are paramount. Its advanced features and certifications make it a trusted choice for professionals seeking high-performance cleanroom flooring options.
Key Features and Benefits
Electroconductive Properties: GTI EL5 CLEANTECH tiles offer permanent electroconductive properties, ensuring effective ESD control throughout their lifespan. The flooring's construction includes carbon encapsulated granules and a conductive backing, providing consistent conductive performance .
Evercare™ Surface Treatment: The patented Evercare™ conductive surface treatment provides exceptional resistance to stains and chemicals, including those used in decontamination processes. This treatment eliminates the need for waxing, simplifying maintenance routines and reducing long-term upkeep costs.
Robust Construction: With a total thickness of 6.0 mm and a 2.0 mm wear layer, these tiles are built to withstand heavy traffic and loads. The double reinforced fiberglass grid enhances dimensional stability and durability.
Easy Installation: The interlocking design allows for adhesive-free installation, making it ideal for renovation projects where minimizing downtime is essential. Tiles can be installed over existing floors like tiles, ceramic, and concrete.
Environmental Sustainability: GTI EL5 CLEANTECH tiles are environmentally friendly, containing 80% recycled content and being 100% recyclable. They are FloorScore® certified, contributing to healthier indoor air quality with ultra-low VOC emissions (<10 µg/m³ after 28 days).
GTI EL5 CLEANTECH DETAILS
Format: Square tile
Dimensions: 25.59 in x 25.59 in (650 mm x 650 mm)
Overall Thickness: 0.24 inch (6.0 mm)
Wear Layer Thickness: 0.08 inch (2.0 mm)
Surface Treatment: Evercare™
Installation: Adhesive-free interlocking system
Slip Resistance: R9
Fire Rating: Bfl-s1
Recycled Content: 80%
Recycling Rate: 100%
TVOC After 28 Days: <10 µg/m³
Certifications: ISO 5, GMP Class A, FloorScore®
Specs
| Applications | Cleanrooms |
|---|---|
| Flooring Category | Cleanroom Flooring, ESD Flooring |
| Industry | Aerospace & Defense, Biotechnology, Cleanrooms, Laboratories, Pharmaceutical Manufacturing, Semiconductor Manufacturing |
| Format | Heat-welded Tiles |
| Thickness | 0.24" (6.0 mm) |
| ESD | ESD CONTROL |
| ISO Level | ISO Class 05, ISO Class 06, ISO Class 07, ISO Class 08, ISO Class 09, ISO Class 10 |
| Color | Black, Blue, Gray, Tan |
GTI EL5 CLEANTECH 0354 BLUE
GTI EL5 CLEANTECH 0353 BEIGE
GTI EL5 CLEANTECH 0352 GREY
GTI EL5 CLEANTECH 0351 BLAC
GTI EL5 CLEANTECH 0350 LIGHT GREY
